2-37
Confidential
Error Code 6A
The ASF encoder sensor cannot detect the rotation of the ASF motor.
<User Check>
Remove the jammed paper in jam clear cover part, platen part and front part.
Error Code 6C
Overcurrent protection was activated in the driver IC of the ASF motor.
Error Code 6F
ASF motor cannot stop.
Unable to print 6A
LCD
Step Cause Solution
1 Foreign materials in the recording
paper feeding path
Remove foreign materials.
2 ASF motor harness connection
failure
Reconnect the ASF motor harness.
3 ASF encoder sensor harness
connection failure
Reconnect the ASF encoder sensor harness.
4 ASF motor defective
ASF encoder defective
Replace the maintenance unit.
5 Main PCB defective Replace the main PCB.
Unable to print 6C
LCD
Step Cause Solution
1 Foreign materials in the
maintenance unit part
Remove foreign materials.
2 Foreign materials in the engine
gears
Remove foreign materials.
3 ASF motor defective Replace the maintenance unit.
4 Main PCB defective Replace the main PCB ASSY.
Unable to print 6F
LCD
Step Cause Solution
1 ASF motor harness connection
failure
Reconnect the ASF motor harness.
2 ASF encoder sensor harness
connection failure
Reconnect the ASF encoder sensor harness.
3 Carriage motor harness
connection failure
Reconnect the carriage motor harness.
4 Paper feed motor harness
connection failure
Reconnect the paper feed motor harness.
5 ASF motor defective
ASF encoder defective
Replace the maintenance unit.
6 Main PCB defective Replace the main PCB ASSY.
