1.3.33 Equipment Error Code Indication (Maintenance mode 82)
<Function>
This function displays an error code of the last error on the LCD.
<Operating Procedure>
(1) Press the [8] and [2] keys in this order in the initial stage of the maintenance mode.
The machine displays "MACHINE ERR XX" on the LCD.
Tip If two or more errors have occurred, press the [Mono Start] key to cycle through the error
codes.
(2) Press the [Stop] or the [X] key to return the machine to the initial stage of the maintenance
mode.
1.3.34 Output of Transmission Log to the Telephone Line (Maintenance mode 87)
<Function>
This function outputs the transmission log to the telephone line. It allows the service personnel to
receive the transmission log of the user’s machine at a remote location and use it for analyzing FAX
transmission problems arising in the user’s machine.
<Operating Procedure>
- At the service site
(1) Call the user’s machine at a remote location from your machine.
- At the user site, have the user perform the following.
Touch panel model
(2) With the machine on standby, hold down the [Home] key to switch the LCD screen.
(3) Hold down the lowermost blank field to switch the LCD screen.
(4) Press the [*], [0], [#], [8], and [7] keys in this order.
Rubber key panel model
(2) When the machine is on standby, press the [Menu], [Mono Start], and [Menu] keys in order.
(3) Press the [8] and [7] keys in this order.
The machine displays "SENDING P.01" on the LCD and transmits the error list.
Upon completion of error list transmission, the machine returns to the standby state.
