3-76
Confidential
(2) Pull the tube support plate tab upward, release the reverse side boss, slide the plate to the right,
and remove it from the lower cover.
(3_099)
Tube support wire
Tab (with a boss on the reverse side)
Tube support plate
Lower cover
