Brother MFC-J285DW Service Manual

2-18
Confidential
*1
Fax communication establishment: Fax communication is established when DIS (presentation
signal of receiving conditions) is received from the calling station, and when NSS or DCS
(communication test signal) is received from the calling station.
Code 1 Code 2 Cause
Reference
Page
B0 01 Detect polarity reversion. Section
4.9.3 "A
communicat
ions error
occurs"
B0 02 Unable to receive the next-page data.
B0 03
Unable to receive polling even during turn-around transmission
due to call reservation.
B0 04 A PC interface error occurred.
BF 01
The [Stop] key was pressed and communication was cancelled
before fax communication could be established
*1
.
BF 02
The [Stop] key was pressed and communication was cancelled
after fax communication was established
*1
.
C0 01 There is no common modulation mode or the polling has failed.
C0 02 JM cannot perform detection.
C0 03 CM cannot perform detection.
C0 04 Unable to perform CJ detection.
C0 10 V.34 negotiation or training does not end.
C0 11
A modem error was detected during V.34 negotiation or
training.
C0 20 A modem error was detected during sending of commands.
C0 21 A modem error was detected during receiving of commands.
C0 22 The control channel connection timed out.
C0 30 A modem error was detected during sending of image signals.
C0 31 A modem error was detected during receiving of image signals.
E0 01
1300 Hz signal detection failed the counter-communication
inspection.
E0 02
PB signal detection failed the counter-communication
inspection.
E0 03
A command was not detected from RS232C through counter-
communication.

Brother MFC-J285DW Specifications

General

Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Economical printing	Yes
Print speed (ISO/IEC 24734) mono	12 ipm
Print speed (ISO/IEC 24734) color	10 ipm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, File, Image, OCR
Scanner type	Flatbed scanner
Image formats supported	BMP, JPG, PCX, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	HTM, PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Fax transmission speed	7 sec/page
Digital sender	-
Maximum duty cycle	2500 pages per month
Number of print cartridges	4
Total input capacity	100 sheets
Total output capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Glossy paper, Photo paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Photo paper sizes (imperial)	4x6, 5x7, 5x8 \
Paper tray media weight (imperial)	4 - 6 lbs
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	1.8 \
Market positioning	Home & office
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	SSID, WEP, WPA-PSK, WPA2-PSK
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, Picasa, Sky Drive
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Sound pressure level (copying)	50 dB
AC input voltage	100 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR
Package depth	457 mm
Package width	477 mm
Package height	228 mm
Package weight	9380 g
Storage temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	373 mm
Width	409 mm
Height	160 mm
