4. SCREW TORQUE LIST
Note:
For verifying the shape of each screw, refer to “3. SCREW CATALOGUE” in this chapter.
Location of screw Screw type Q' ty
Tightening torque
N
·m (kgf·cm)
Fuser cover L Taptite bind B M4x12 2 0.8±0.1 (8±1)
Fuser cover R Taptite bind B M4x12 2 0.8±0.1 (8±1)
Fuser unit Taptite pan B M4x14 2 0.8±0.1 (8±1)
Side cover L Taptite B 3x6 1 0.45±0.05 (4.5±0.5)
Taptite bind B M4x12 4 0.8±0.1 (8±1)
Side cover R Taptite B 3x6 1 0.45±0.05 (4.5±0.5)
Taptite bind B M4x12 3 0.8±0.1 (8±1)
Duplex tray Taptite cup B M3x12 2 0.5±0.1 (5±1)
Front cover damper spring
Taptite B 3x6 1 0.3±0.05 (3±0.5)
Back cover upper Taptite bind B M4x12 2 0.8±0.1 (8±1)
Panel FG harness Screw bind M3x8 1 0.5±0.05 (5±0.5)
Main shield cover plate
ASSY
Screw bind M3x8 (Upper side) 1 0.5±0.05 (5±0.5)
Screw bind M3x8 (Lower side) 2 0.8±0.1 (8±1)
ADF earth harness Screw bind M3x8 1 0.5±0.05 (5±0.5)
Document scanner FG
harness
Screw bind M3x8 1 0.5±0.05 (5±0.5)
ADF unit Taptite bind B M4x12 2 0.8±0.1 (8±1)
Hinge ASSY L Taptite cup S M3x12 3 0.8±0.1 (8±1)
Hinge R support Taptite cup B M3x10 1 0.5±0.05 (5±0.5)
Document scanner unit Taptite bind B M4x12 4 0.7±0.1 (7±1)
Taptite cup B M4x12 2 0.7±0.1 (7±1)
Upper ADF chute Taptite cup B M3x10 1 0.5±0.05 (5±0.5)
ADF unit Taptite cup B M3x10 1 0.5±0.05 (5±0.5)
Upper ADF chute Taptite cup B M3x10 5 0.5±0.05 (5±0.5)
Lower ADF chute Taptite cup B M3x10 3 0.5±0.05 (5±0.5)
ADF FG harness Taptite cup S M3x8 SR 1 0.7±0.1 (7±1)
Drive frame ASSY Taptite cup B M3x10 3 0.5±0.05 (5±0.5)
ADF motor Screw pan (S/P washer) M3x6 1 0.6±0.1 (6±1)
Control panel ASSY
(A4 model)
Taptite cup B M3x10 4 0.5±0.1 (5±1)
Control panel ASSY
(Legal model)
Taptite bind B M4x12 2 0.7±0.1 (7±1)
LCD hold plate Taptite cup B M3x10 3 0.45±0.05 (4.5±0.5)
Panel control PCB shield
plate cover
Taptite cup B M3x10 4 0.45±0.05 (4.5±0.5)
Document scanner top
cover ASSY
Taptite bind B M4x12 6 0.7±0.1 (7±1)
