5-23
Confidential
1.3.12 EEPROM Dump Print (Function code 40)
<Function>
This function is to print the EEPROM information.
<Operating procedure>
(1) Press the 4 and 0 keys in this order in the initial state of the maintenance mode.
“E2PDUMP ENGN ALL” is displayed on the LCD.
(2) Press the or key to select the information you wish to print. Press the SET key, and
then the “E2DUMP PRINT” is displayed on the LCD.
(3) Press the SET key, and then the “E2DUMP PRINTING” is displayed on the LCD.
The printer starts to print the EEPROM log.
(4) Upon completion of EEPROM logs printing, the machine returns to the initial state of the
maintenance mode.
The terms of EEPROM logs on the LCD are as follows;
Note:
- Press the X key and finish this operation to return the machine to the initial state of the
maintenance mode.
- If an error occurs during printing, it is necessary to start from the beginning.
- The serial number of the machine is printed on the first line on each page.
LCD Description
E2PDUMP ENGN ALL Print of all the values stored in the E2PROM of the engine control
unit. (print of 1 page)
E2PDUMP MAIN TOP Print of the values stored in the E2PROM corresponding to the
top 1 Kbytes of the main controller. (print of 1 page)
E2PDUMP MAIN BTM Print of the values stored in the E2PROM corresponding to the
last 1 Kbytes of the main controller. (print of 1 page)
E2PDUMP MAIN REG Print of the values stored in the E2PROM of the information
related to the compensation values of the main controller.
(print of 1 page)
E2PDUMP MAIN ALL Print of all the values stored in the E2PROM of the main
controller. (print of 8 pages)
To Next Page
