1.2 List of Maintenance-mode Functions
Function
code
Function Refer to:
01 EEPROM parameter initialization 1.3.1 (5-5)
05 Printout of scanning compensation data 1.3.2 (5-6)
08 ADF performance test 1.3.3 (5-8)
09 Monochrome image quality test pattern 1.3.4 (5-9)
10 Worker switch (WSW) setting 1.3.5 (5-10)
11 Printout of worker switch (WSW) data 1.3.5 (5-10)
12 Operational check of LCD 1.3.6 (5-14)
13 Operational check of control panel key 1.3.7 (5-15)
25 Software version check 1.3.8 (5-16)
28 “One Push Demo” setting 1.3.9 (5-17)
32 Operational check of sensors 1.3.10 (5-18)
33 LAN connection status display 1.3.11 (5-22)
40 EEPROM Dump Print 1.3.12 (5-23)
41 Backup of machine information 1.3.13 (5-24)
43 PC print function setting 1.3.14 (5-26)
45 Changing return value of USB No./
Switching Dither Pattern/Switching of ON/OFF of
DirectPrint Color mode-Improve Gray Color/Switching
of timing to execute Auto Registration/
Adjusting left-end print start position on second side in
duplex printing/Change of the transfer current setting/
Change of ghost reduction setting
1.3.15 (5-29)
52 Set country/language 1.3.16 (5-33)
53 Transfer of received fax data and log information 1.3.17 (5-34)
54 Fine adjustment of scan positions 1.3.18 (5-36)
55 Acquisition of white level data and setting of CIS
scanning area
1.3.19 (5-37)
57 Motor reset 1.3.20 (5-38)
61 Adjustment of touch panel 1.3.21 (5-39)
66 Adjustment of color registration
(Adjustment of inter-color position alignment)
1.3.22 (5-40)
67 Continuous print test 1.3.23 (5-44)
68 Laser unit test pattern print 1.3.24 (5-48)
69 Frame pattern print (One-sided) 1.3.25 (5-49)
70 Frame pattern print (Two-sided) 1.3.26 (5-50)
71 Color test pattern 1.3.27 (5-51)
72 Sensitivity adjustment of density sensor 1.3.28 (5-54)
