5-44
Confidential
1.3.23 Continuous print test (Function code 67)
<Function>
This function is used to conduct paper feed and eject tests while printing patterns.
<Operating procedure>
(1) Press the 6 and 7 keys in this order in the initial state of the maintenance mode. “SELECT:
K 100%” is displayed on the LCD.
(2) Referring to the <Print pattern> table, press the or key to select the desired print
pattern and press the SET key. “SELECT: A4” is displayed on the LCD.
(3) Referring to the <Paper size> table, press the or key to select the desired paper
size and press the SET key. “SELECT: PLAIN” is displayed on the LCD.
(4) Referring to the <Print specifications> table, press the or key to select the desired
media specifications and press the SET key. “SELECT: TRAY1 SX” is displayed on the
LCD.
(5) Referring to the <Print type> table, press the or key to select the desired print type
and press the SET key. “SELECT: 1PAGE” is displayed on the LCD.
(6) Referring to the <Number of pages to be printed> table, press the or
key to select the desired number of pages to be printed and press the SET key. For the
intermittent pattern printing only, “SELECT: 1P/JOB” is displayed on the LCD. For other
than intermittent pattern printing, go to step (8).
(7) Referring to the <Number of pages per job> (Intermittent pattern printing only) table, press
the or key to select the desired number of pages per job and press the SET key.
(8) “PAPER FEED TEST” is displayed on the LCD and the test pattern starts to be printed
under the selected items for paper feed test.
(9) If you press the X key, printing of test pattern is interrupted and the machine returns to the
initial state of the maintenance mode.
To Next Page
