Brother MFC-L8850CDW Service Manual

3-11
Confidential
Harness colors may be changed for any reason.
2 Process Drive Unit, Front Cover Sensor, Main Drive Unit
3 Develop Release Drive Unit, Develop Release Sensor PCB ASSY,
Toner/New Sensor PCB ASSY
Main PCB
Hook
Hook
Hook
Hook
Hook
Hook
Cable
rack
Front
CN31
CN16
CN19
CN12
CN18
Wireless LAN
cable rack
Main drive unit
PF cable rack
Process
drive unit
Main motor
Process motor
Registration
T1 solenoid
harness (BK)
Front cover sensor
Front cover
flat cable
Hook
CN45
CN30
solenoid
Main
harness ASSY
Develop
clutch harness
(BK)
Hook
ASSY
flat cable
harness (BK)
LT-drawer
sensor harness
(RD, WH)
Hook
Hook
Hook
Hook
CN21
CN10
Develop release
Toner/new sensor
Develop release drive unit
Develop release clutch harness (BL)
CN2
Main PCB ASSY
Wireless
Toner/new sensor harness ASSY
(BL, WH, RD)
Develop release
sensor harness ASSY
(BL, WH, RD)
Hook
Paper eject ASSY
Hook
sensor PCB ASSY
PCB ASSY
LAN
cable rack
Main frame L ASSY

Brother MFC-L8850CDW Specifications

General

Type	all in one
Color	white
Tray Capacity	300
Automatic Document Feeder Capacity	50 sheets
Paper Size	8.5"x14"
Paper Handling	up to 300 sheets
Color Print Speed	32 pages per minute
Mono Print Speed	32 pages per minute
Print Resolution Color	up to 2400 x 600
Maximum Number of Pages Per Month	unknown
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 600 x 600
Copier Resolution Color	up to 600 x 600
Cartridges	tn331bk, tn331c, tn331m, tn331y
Number Of Cartridges	4
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	usb, google cloud print
OS Compatibility	windows, mac os, linux
Mobile Devices Connection	yes

Weight and Dimensions

Height	19.3 inches
Width	20.7 inches
Net Weight	67.4 pounds
