Brother MFC-L8850CDW Service Manual

3-20
Confidential
Harness colors may be changed for any reason.
14 ADF (Legal model)
Front
CN33
CN37
Main PCB
Hook
Hole
Hook
Hook
Main PCB ASSY
CN41
CN39
Hole
Second side
Document cover ASSY
Drive frame
ADF unit
Flat cable holder
Document
scanner unit
Document
scanner unit
Joint cover top
Joint cover top
Flat core
Hole
Second side CIS flat cable
Hole
Harness
of the ADF unit
Upper ADF chute
ASSY
ASSY
Core
Front
Document cover ASSY
Hook
Hook
Hook
Drive frame ASSY
ADF earth
harness
First side document
scanning position
sensor PCB ASSY
ADF motor
harness
Second side document scanning
position sensor PCB ASSY
ADF cover/document
detection sensor PCB ASSY
Hole
ADF unit
Hook
Front
Front
Hook
Hole
CIS unit
“A”
“A”
Screw bind M3x8

Brother MFC-L8850CDW Specifications

General

Type	all in one
Color	white
Tray Capacity	300
Automatic Document Feeder Capacity	50 sheets
Paper Size	8.5"x14"
Paper Handling	up to 300 sheets
Color Print Speed	32 pages per minute
Mono Print Speed	32 pages per minute
Print Resolution Color	up to 2400 x 600
Maximum Number of Pages Per Month	unknown
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 600 x 600
Copier Resolution Color	up to 600 x 600
Cartridges	tn331bk, tn331c, tn331m, tn331y
Number Of Cartridges	4
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	usb, google cloud print
OS Compatibility	windows, mac os, linux
Mobile Devices Connection	yes

Weight and Dimensions

Height	19.3 inches
Width	20.7 inches
Net Weight	67.4 pounds
