Brother MFC-L8850CDW Service Manual

3-120
Confidential
■ A4 model
Fig. 3-159
■ Legal model
Fig. 3-160
Assembling Note:
When the Document scanner unit are replaced, be sure to fold and assemble the First side
CIS flat cable as shown in the figure.
Fold down
Fold back
<To be connected to Main PCB>
<To be connected to
140±1 mm
414±1 mm
289±1 mm
(10±1.5 mm)
0 to 3
45°
45°
40 mm
20 mm
20 mm
Fold the flat cable at the
edge of the Supporting plate.
Surface of the Supporting plate
(Back side: Terminal surface)
Surface of the Supporting plate
(Back side: Terminal surface)
Affix the tape on the
back side
(terminal side).
39±1 mm
First side CIS unit>
0 to 3
<To be connected to Main PCB>
Fold down
Fold back
113±1 mm
471±1 mm
317±1 mm
39±1 mm
(10±1.5 mm)
(10±1.5 mm)
45°
45°
40 mm
20 mm
20 mm
Surface of the Supporting plate
(Back side: Terminal surface)
Affix the tape on the
back side
(terminal side).
Surface of the Supporting plate
(Back side: Terminal surface)
Fold the flat cable at the
edge of the Supporting plate.
Fold the flat cable at the edge
of the Supporting plate.
<To be connected to
First side CIS unit>

Brother MFC-L8850CDW Specifications

General

Type	all in one
Color	white
Tray Capacity	300
Automatic Document Feeder Capacity	50 sheets
Paper Size	8.5"x14"
Paper Handling	up to 300 sheets
Color Print Speed	32 pages per minute
Mono Print Speed	32 pages per minute
Print Resolution Color	up to 2400 x 600
Maximum Number of Pages Per Month	unknown
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 600 x 600
Copier Resolution Color	up to 600 x 600
Cartridges	tn331bk, tn331c, tn331m, tn331y
Number Of Cartridges	4
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	usb, google cloud print
OS Compatibility	windows, mac os, linux
Mobile Devices Connection	yes

Weight and Dimensions

Height	19.3 inches
Width	20.7 inches
Net Weight	67.4 pounds
