Brother MFC-L8850CDW Service Manual

2-10
Confidential
T2 separation roller,
T2 separation pad
Separates the paper fed from T2 paper tray unit into single
sheets.
T2 paper feed actuator
(T2 paper feed sensor)
Detect whether or not the T2 paper tray unit is installed
(open or closed). Detect the paper jam of front part.
Paper eject origin sensor Detect the eject/reverse position state of the gear of the
paper eject ASSY.
Document pick-up roller Feed the documents from ADF document support to the
scanning part.
Document separate roller,
ADF separation pad
Separates the documents fed from ADF document support
into single sheets.
Document detection actuator
（Document detection sensor ）
Detect whether documents are set in the ADF.
First side/Second side
document scanning position
actuator
（Document scanning position
sensor ）
Detect the scanning start position of the first and second
sides. Detect paper jam in the ADF.
Document ejection roller Feed the documents to the document cover.
ADF cover sensor Detect whether the ADF cover is opened or closed.
Part name Operation

Brother MFC-L8850CDW Specifications

General

Type	all in one
Color	white
Tray Capacity	300
Automatic Document Feeder Capacity	50 sheets
Paper Size	8.5"x14"
Paper Handling	up to 300 sheets
Color Print Speed	32 pages per minute
Mono Print Speed	32 pages per minute
Print Resolution Color	up to 2400 x 600
Maximum Number of Pages Per Month	unknown
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 600 x 600
Copier Resolution Color	up to 600 x 600
Cartridges	tn331bk, tn331c, tn331m, tn331y
Number Of Cartridges	4
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	usb, google cloud print
OS Compatibility	windows, mac os, linux
Mobile Devices Connection	yes

Weight and Dimensions

Height	19.3 inches
Width	20.7 inches
Net Weight	67.4 pounds
