Brother MFC-L8850CDW Service Manual

5-20
Confidential
Fig. 5-7
Fig. 5-8
MP paper empty
MP registration
Waste toner sensor
New toner sensor (Yellow)
New toner sensor (Magenta)
New toner sensor
New toner sensor
Toner sensor (Yellow)
Toner sensor (Magenta)
Toner sensor (Cyan)
Toner sensor
(Cyan)
(Black)
(Black)
Develop release sensor
PCB ASSY
MP paper empty/registration front
sensor PCB ASSY
MP upper cover
front sensor
ASSY
Toner/new sensor
sensor
PCB ASSY
T2 paper feed sensor
Back cover sensor
Eject sensor
T2 plate origin sensor
T2 connect sensor
Belt temperature sensor
Internal temperature
Paper eject ASSY
Registration mark
sensor unit
Low-voltage power
Registration mark
sensor L PCB
Registration mark
sensor R PCB
T2 paper feed frame unit
supply PCB unit
sensor

Brother MFC-L8850CDW Specifications

General

Type	all in one
Color	white
Tray Capacity	300
Automatic Document Feeder Capacity	50 sheets
Paper Size	8.5"x14"
Paper Handling	up to 300 sheets
Color Print Speed	32 pages per minute
Mono Print Speed	32 pages per minute
Print Resolution Color	up to 2400 x 600
Maximum Number of Pages Per Month	unknown
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 600 x 600
Copier Resolution Color	up to 600 x 600
Cartridges	tn331bk, tn331c, tn331m, tn331y
Number Of Cartridges	4
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	usb, google cloud print
OS Compatibility	windows, mac os, linux
Mobile Devices Connection	yes

Weight and Dimensions

Height	19.3 inches
Width	20.7 inches
Net Weight	67.4 pounds
