Maintenance
H148850_3_003 57
Procedure:
• Use a clean cloth to remove surface dust.
• Dampen a new cloth with the cleaning solution.
• Wipe the enclosure.
• Dry by gently buffing with a new cloth.
Avoid scratching the cover while drying. The autosampler and enclosure must be
thoroughly dry before you turn the power on.
10.3 Mounting the Z-Drive Assembly
Follow these instructions if you need to mount the Z-drive after cleaning or maintenance.
Reverse the steps if you need to remove the Z-drive.
10.3.1 Tools Required
You will need the following tools:
• Phillips-head screwdriver.
NOTICE
Device Damage Hazard
Plugging in or unplugging the device cable with the power on may cause serious damage to
the device.
u Plug in the device cable before powering on the device.
u Do not unplug the power cable with the device powered on.
• Turn off the sample changer.
• Slide the carriage to the end of the Y-arm.
Figure10.1: Positioning the Carriage.
