10.3.3 Connecting the Pneumatic Tubing
• Connect the tubing to the appropriate fittings on the back of the sample changer.
Figure10.8: Gripper Tubing Connection on Back of Sample Changer
• Connect the tubing to the appropriate fittings on the gripper.
Figure10.9: Gripper Tubing Connected to the Gripper on the Z-Drive
