10.3.2 Using Tubing Tamers
• Attach the Tubing Tamer to the Z-Drive. Run any communications wires and sample
tubing along the Z-Drive cable through the tamers.
Figure10.6: Connecting Tubing Tamer
Figure10.7: Tubing Tamer Properly Installed on Z-Drive Cable
