10.3.4 Connecting the Auxiliary Connector
• Connect the wires from the gripper to the auxiliary connector as shown.
Figure10.10: Auxiliary Connector
• Route the tubes and wires through the tubing tamers. Make sure that the tubes and wires
are positioned so that they will not catch on anything when the sample changer moves.
Figure10.11: Tubing After Installation
