T419S Indicator Service Manual 45
6.3 System menu
Lst Smp Activate this to see the Last sample size value. The last sample size
parameter represents the number of pieces used during the last sample
routine to determine the current average piece weight. Only one last
sample size parameter is maintained for all enabled scales.
ROC Rate of Change
USRMSG User message (Macros only)
VAR User variable
6.3.5 Tare
Use this item to set the type of tare entry and the tare autoclear functions.
PushBt This stands for pushbutton tare. Enable this to use the TARE key to tare
weight from the scale. on is the default value.
Enter This stands for keypad entry tare. Enable this and you can key in a tare
value and press TARE to activate it during normal weighing mode. Off is
the default.
Preset This stands for preset tare. Preset tare values are entered in a password
protected menu and can be recalled, if this parameter is enabled. Off is the
default value.
TareCl This stands for automatic tare clear. Enable this to automatically clear a
tare after a weighment when the weight falls into the gross zero band. Off
is the default value.
HiRes This stands for high resolution tare. If On, the indicator does not round the
tare value to the current division size. Choose On to enable high resolution
tare or Off to disable high resolution tare. Default is Off.
6.3.6 Config
Use this to print out the configuration data through one of the ports or reset the
configuration or calibration to factory defaults. Follow these steps:
Print Use this to print the indicator configuration information. You pick the port
to use for printing in the following steps. See the extensive list in Chapter
9 - Printed reports (page 89)
Choices are Port 1, Port 2, Port 3 and USB (text file).
Pushbutton and keyboard entry tare can both be set to on simultaneously. The TARE
key must be enabled in the Button menu.
If USB is selected, a USB flash drive must be installed to create the text file of the
indicator configuration.
