T419S Indicator Service Manual 53
6.4 Ports menu
Bind x - In this item you choose the physical connection, or hardware, for the
communication for Protocol x: Port 1-3, Enet 1 through Enet 10, File,
O.B1.C1, O.B1.C2, O.B1.C1, O.B2.C2, Prtr 1, Prtr 2 or Prtr.USB. Some
Bindings will not apply for certain Type selections.
Attr x- In this item you choose the print format and other properties that are
required for the Type and Binding selected for Protocol x. Some attributes
will not apply for certain Types or Binding combinations.
PrnFt, Choose a print format from the documented list. Key in the
format number. Print format 1 is the default.
Inhib This is motion inhibit. Choose On to enable or Off to disable.
If enabled, data transmission or file creation will be inhibited
until there is no motion on the scale or until the process times
out. Off is the default.
Rate This is the transmit rate associated with broadcast type.
Choices are 1, 2, 5, 10, 20, 50, 80 or 100 Hz.
Address Key in the node address if using an RS-485 option in a
multidrop network. Choices are 0 to 255.
Enq Key in the enquire character used to request a print function
to occur from the communications port. Choices are 0 to 255.
5 is the default value (ASCII ENQ character).
Enq2 This functions the same as pressing the PRINT key.
If Archive is enabled, this can be used for Archive reporting
to add the transaction record and increment the counter. The
default value is 7 (ASCII BEL character). Choices are 0 to
255.
Scale In the SMA and NCI protocols this links that protocol to that
Scale for getting and setting of Data.
In the Broadcast and Enquire Protocols this determines which
scale the received commands refer to.
6.4.4 P.F. Edit
This stands for print format editor. Please refer to the section Print formatting on page
91 for the procedures to edit or create print formats.
O.B1.C1 refers to the option module in the Bus 1 and Card 1 position, O.B1.C2 refers
to the option module in the Bus 1 and Card 2 position, etc.
