98 T419S Indicator Service Manual

10 Print formatting

10.4 Other scale tokens

In addition to the above, you can examine the tokens available and do much more with

the data. For example suppose the Customer’s PC can’t cope with decimal point in the

weight value from the scale. We can add optional parameters after the Gross weight

token to remove the decimal point. This print format character sequence would look like

this …

[ = t501 indicates the start of an optional parameter

68 = D for decimal point parameter

50 = 2 for hide decimal point

] = t502 indicates the end of the optional parameter

The above token and function will output the text “Gross”

The above token and function will output the Gross weight value.

Characters 5 to 8 will remove the decimal point from the weight transmitted using an

attribute parameter. You may need to refer to the Network tokens on page 110 for

more detail on necessary character values.
