T419S Indicator Service Manual 93
10.2 Editing an existing print string
10.2.1 Inserting characters
1. To insert characters into a print string, press and hold the DOWN arrow key.
After you hold the DOWN arrow key for about 3 seconds the Index number will
start to automatically increment by 1 about every second as Spaces (dec 32)
are inserted into the print string. You will still see the current string character on
the right side of the display but the string index number will increment as spaces
are inserted in front of this character. So for this example, press and hold
DOWN arrow until the display shown below appears, then release the DOWN
arrow key …
2. To start the entry of the company name press the LEFT arrow key to scroll
backwards until string index number 1 is again displayed, as shown below.
3. Press DOWN arrow and the display shows a number entry screen. This allows
you to enter a new character.
4. Use the numeric keypad and type in 65, the decimal value for A, and press
ENTER …
The following is displayed:
5. Press the RIGHT arrow key to advance to the next string index number and
press the DOWN arrow key …
The number entry screen is displayed again.
6. Enter the value for the next letter in the company name and press ENTER.
7. Repeat steps 5 and 6 until the last character is entered. In this example that
would be 13, 10 for the line feed.
Press Down to Edit, Enter to Save
Esc
Arrows Scroll Left/Right
14, 032
Press Down to Edit, Enter to Save
Arrows Scroll Left/Right
1, 032
Press Down to Edit, Enter to Save
Esc
Arrows Scroll Left/Right
1, 065
