T419S Indicator Service Manual 57
6.4 Ports menu
D_T This will create a new file and the file name will be appended
with the date and time (including seconds) for each
transaction.
Reset Reset will clear all stored transactions and also reset the numbered file
sequence to 000001.
6.4.8 Options
Use this parameter to enable any of the available option cards.
Bus 1or2 Choose the Bus.
Card 1or2 Choose the card position.
Type Choose the type of card installed from this list:
l None
l USB Device option card
l Analog output card
l Wireless Ethernet communication (802.11g) card
l Current Loop/RS485/RS422 card
The Scale menu item is for this input cards
l Analog Scale Input Option with 5VDC Excitation
l Analog Scale Input Option with 10 VDC Exit. and STVS
The Ext IO menu item is for the following I/O interface card:
l External I/O Interface card
l AC Input 4 relays (120-240VAC) card
l DC Input 4 relays (4-30VDC) card
l AC Output 4 relays (20-240VAC) card
l DC Output 4 relays (3-60VDC) card
l DeviceNet
TM
(DevNet)
l Profibus
©
Filename Examples:
<ScaleName>_<SERIAL>XXXXXX.txt
where <ScaleName> is the scale name, <Serial> is the serial number, XXXXXX is
either nothing, the sequential number, or the time and date.
Sequential number increments from 000001 – 999999 …. when RESET starts at
000001
Date = YYYY_MM_DD__HH_MM_SS
with double underscore between DD and HH
Examples:
Constant: ScaleName_120450001.txt
Numbered: ScaleName_120450001_000001.txt
D_T: ScaleName_120450001_2012_01_31__10_31_23.txt
If transactions are being store on the indicator Flash memory, only a single Constant
or Numbered file will be created. If using the Date & Time file naming convention then
individual files will be created.
