BTEK T419S Service Manual

52 T419S Indicator Service Manual
6 ADMIN Menu
ENQ Choose this to send data when the indicator receives the
configured enquire code from an external device. The
information will be sent through the selected binding using the
associated attributes. See ENQ & B-Cast commands on page
65.
SMA Choose this to send and receive data when using the SMA
(Scale Manufacturers Association) protocol. See SMA
Protocol on page 60. The information will be sent through the
bound port using attributes that are predefined by the SMA
protocol.
B-Cast Choose this to send data continuously through the selected
binding using the associated attributes. Typical use is for
remote scoreboards, displays and the Analog output option
if installed. See ENQ & B-Cast commands on page 65.
PLC Choose this to send and receive data to/from a PLC network.
A binding of Enet x (1 through 10) is required. The attributes
are established using the PLC menu described later in this
manual. See PLC Configuration information on page 67.
FTP Choose this to send data via FTP. A binding of Enet x (1
through 10) is required. The Rate attribute determines the
time (in minutes) between attempted FTP updates. A second
Protocol is required to complete the FTP setup. This
additional protocol requires a Type x = PRINT, Bind x = File
and Attributes x will need a Print Format. Also, set File Path
= FTP and define the File Mode (File naming convention) in
the File menu described later in this manual.
RD Choose this to use the indicator as a remote display. When
set as a remote display, the indicator will only function as a
remote display for the connected primary indicator which is
connected to the weighing platform. This requires a special
application.
NCI Choose this to use the NCI communication protocol. See
NCI commands on page 66.
Report Choose this for reports using footers and headers. This
requires a special application.
BSQ Choose this when using a BSQ base.
intPrt This stands for input interpreter. Choose this when using
macros. This can only be configured via Ztools. See the
warning below.
App Application dependent, used for data exchange port selection.
Hid Use to configure an input device type, i.e. bar code scanner,
RFID reader, etc., for serial, ethernet or USB interface.
ZB210 Choose this when using a ZB210 digital junction box.
WARNING: If using Input Interpreter, do NOT change to another TYPE from the
front panel or Input Interpreter will not be available without reconfiguring from
Ztools.
