47
8175
ENGLISH
TEST MENU
4.5 TEST MENU
PRESS SIMULTANEOUSLY FOR 5 SECONDS
The following parameters are selected and set within this menu;
SECTIONS
The follwing sections explain how to change and investigate the parameter
values within the test menu above.
0......9
4.5.1
4.5.2
4.5.3
4.5.4
4.5.5
4.5.6
Zero point compensation (4 mA).
Span compensation (20 mA).
Temperature correction +/- 15
°C
.
Display of the returned signal strength.
Input of the level, volume or temperature
to be simulated. The current and relay
outputs will react according to this value.
Reset of the device to the factory
settings and reseting of the interference
table.
Return to the main menu and store the
new parameters. If one of the two
values for OFFSET and SPAN is
inappropriate, the device will
automatically return to the "OFFSET"
parameter and new values must be
entered.
OFFSET
SPAN
SIGNAL
T° ADJUST
END
SIMUL
RESET
0......9
ENTER
4.5
