4
8175
ENGLISH
QUICKSTART
See section 6.7
Unpacking
Verify
Ident. No.
Select the
mounting position
Have you
a separate
version?
Have you
a cable plug
version?
Connect power
supply cable
Connect output
cable
Reassemble
housing or plug
Turn on the
power
Distance
displayed
coherent?
Program the transmitter
2.1 INSTALLATION
O.K
Yes
No
Verification of items received
See section 6.5
Contact your local Bürkert
subsidiary.
See section 3.4
Unscrew the plug
screws and open
Unscrew the 4
screws and open
Install the unit
on the fitting
Check electrical
connection
This section provides a comprehensive installation and operation guide which will
assist with the commissioning of the 8175 Level Transmitter.
No
See section 3.0
2.1
Yes
No
Ensure that security
provisions are considered
with the power cable and
relay circuit.
Pay attention to the max.
permitted load of
the output current
loop.
If the unit does not work,
See section 5.2
Ensure the power
supply is switched on.
See the next page
.
Ensure the power supply
is disconnected before
starting work.
Connect the
sensor cables
Yes
No
For panel versions
move to the next step.
To Next Page
