Burkert 8175 - Testing

8
8175
ENGLISH
QUICKSTART
To access the TEST MENU simutaneously press for 5 seconds.
2.3 TESTING
0......9
ENTER
Control of
4 mA
Control of
20 mA
Adjustment of the
temperature
Display of the
signal strength
Simulation of
the outputs
Reseting of the
stored parameters
The unit is now ready
The mode Offset fixes the
output current of 4mA.
(optional)
The mode Span fixes the
output of 20mA. (optional)
Verify the real temperature is
near to that of the measured
temperature. (optional)
Orient the transmitter to obtain
the highest signal strength.
This is optional although it is
recommended for
commissioning large systems.
See section 4.5.1
See section 4.5.2
See section 4.5.3
See section 4.5.4
See section 4.5.5
See section 4.5.6
2.3
