ENGLISH
INFORMATION
6.2 HORIZONTAL CYLINDRICAL TANK VALUE CONVERSIONS
For the calculation and input of the measured values for a horizontal cylindrical tank,
both the level % and Volume % relationships have to be calculated and then entered
within the manual input of distances and associated volumes procedure.
To calculate the values a table below has been provided to assist with the
calculations.
After calculating the values perform a volume Teach-In - .
Steps for value calculation
● Identify the maximum level and volume for the application.
● Enter the maximum volume and level within the table (100%).
● Calculate the level values at the respective level percentages for the application
(90% - 0%).
● Calculate the volume values for the respective volume percentages by multiplying
the maximum volume of the application by the volume % within the table and
dividing by 100.
6.2
Level Level Volume Volume
in % (chosen unit) in % (chosen unit)
0 0,00
10 5,20
20 14,24
30 25,23
40 37,35
50 50,00
60 61,64
70 74,77
80 85,76
90 94,79
100 100,00
