Burkert 8175 - Dimensions

58
8175
ENGLISH
INFORMATION
6.3 DIMENSIONS
Cable plug version:
PG 13.5 & G 1/2“ versions:
The dimension ‘A‘ will vary depending on the type of connection selected -
PG 13.5 = 28mm and G 1/2“ = 15mm.
6.3
88 29
DIN 43650
PG9
31
7
70
ø 29
G2’’
80
124,5
137,5
77
45°
88 A
31
7
70
NPT2’’
80
124,5
137,5
77
45°
ø 29
