GasAlertMicroClip
Parts of the GasAlertMicroClip
Parts of the GasAlertMicroClip
Figure 1. Parts of the GasAlertMicroClip
Table 3. Parts of the GasAlertMicroClip
Item Description
1 IntelliFlash
2 Visual alarm indicators (LEDs)
3 Alligator clip
4 Charging connector / IR interface
5 Pushbutton (C)
6 Carbon monoxide (CO) sensor
7
Hydrogen sulfide (H
2
S) sensor
8
Oxygen (O
2
) sensor
9 Combustible (LEL) sensor
10 Audible alarm
11 Liquid crystal display (LCD)
