Print Positions:
The Home position or "Zero point" of a label is shown on the picture below.The "Headline"appears
first, as it is usual on all laser printers etc. Most users prefer to get the printed label "foot first" out of
the printer. This can easily be done when the "O R" command is added to the shown examples.
We did not add this command in the samples to keep a better overview. You may add this whenever
it is required. "O R" rotates the orientation of the label by 180 degrees. So all shown examples which
do not contain the "O R" command have been rotated for a better view in this manual.
Initial Home position
Home position when the "O
R" command had been
used.
The Orientation is identical on all printers as it is shown on a Apollo-series printer as an example.
Initial Home position
Home position when the "O
R" command had been
used.
feed
direction
(paper
path)
