Apollo Hermes
command
available ?
122 cab Produkttechnik GmbH & Co KG
122
PRODUCT MARKING AND BARCODE IDENTIFICATION
[TABLE OF CONTENTS]
[COMMAND LIST][INDEX][ESC][i][L][S]
G - Graphic Field Definition
cab printers are able to print graphic elements, such as lines, rectangles, circles and elipses.
These graphic elements are defined by the G command.
G[:name;]x,y,r;ge:settings[,options]
CR
G = Graphic field definition command.
[:name;] = Optional field name. Maximum length 10 characters, no special
characters allowed, fieldname must be unique. The field name
can be used for further operations, such as Replace field name
(See the "R" command for details) or just as a comment.
x = Horizontal coordinate of the start position in millimeters or inches
from the left edge of the printable area to the start position of the
graphic field.
y = Vertical coordinate of the start position in millimeters or inches
from the top edge of the printable area to the start position of the
graphic field.
Starting points of the graphic elements are:
Lines: Center of the starting point of the line
Rectangles: upper left corner, outside of the rectangle
Circles: Center
Ellipses: Center
r = Rotation. Graphic elements can be rotated in steps of 1degrees
from 0 to 359 degrees
ge = graphic element:
L = Line
R = Rectangle
C = Circle
(Ellipse is defined with the circle command)
settings = specific graphic element settings, depending on the selected
graphic element.
Syntax:
xx
