CAB Apollo Series User Manual

Apollo Hermes
command
available ?
146 cab Produkttechnik GmbH & Co KG
146
PRODUCT MARKING AND BARCODE IDENTIFICATION
[TABLE OF CONTENTS]
[COMMAND LIST][INDEX][ESC][i][L][S]
P - Set Peel-Off Mode
This command needs an optional peel off sensor, which varies from printer type to printer type.
This command pauses the printer after each label. The next label prints, when the actual label is
removed.
P[disp] CR
P = Peel-Off Mode command.
disp = displacement in millimeters or inches (optional parameter)
positive and negative values can be used, depending in which
direction the displacement should work.
The "P" command needs to be placed after the definition of the page size ! ("S"- command)
Syntax:
xx

CAB Apollo Series Specifications

General

Print Technology	Thermal Transfer
Print Resolution	203 dpi, 300 dpi, 600 dpi
Max Print Width	104 mm
Interfaces	USB, Ethernet, RS232
Operating Temperature	+5°C to +40°C
Dimensions	240 mm
