I - Image Field Definition
The I command is used for image printing. ( Image stands for pictures, pictograms, logos etc.).
It defines the position and the size of an image on the label.The image has to be downloaded first,
before it can be placed on the label. (See "d" - download command for more details )
I[:name;]x,y,r[,mx,my];name
CR
I = Image field definition
[:name;] = describes the field name and is optional. The maximum length of this
name is 10 characters, no special characters allowed. A field name
can be used for further operations, such as replacements etc.
(See "R" command for details).
X = The x - coordinate is the horizontal start position of an image (in
millimeters or inches), the distance between the left margin of a label
and the upper left corner of the image.
y = The y - coordinate is the vertical start position of an image, the
distance between the top margin of a label and the upper left corner
of the image.
The maximum coordinate depends on the printer type. Please refer to
the operator´s manual.
r = Rotation -rotates an image in 4 directions. Valid values are 0, 90, 180
and 270. Measurement in degrees.
mx = Horizontal magnification factor. Values 1-10. This parameter is
optional. Enlarges the image horizontally multiplied by this factor.
my = Vertical magnification factor. Values 1-10. This parameter is
optional. Enlarges the image horizontally multiplied by this factor.
Syntax:
xx
