d - download data
We recommend to use monochrome graphics only! The resolution should not be higher than the
printer´s printhead resolution.
name = Filename to be downloaded with a maximum length of 8-digits. This
filename will be recalled on later programming.
[SAVE] = This optional parameter is used for downloading to the printer´s
memory card.
(The memory card commands (M ... explain more possibilities, -
please see there for more details)
The [SAVE] option copies the file from the printers memory to the
memory card.
B: ± value= Sets the brightness of dithering on graphics. Valid values are ± 20.
B:+5 makes the picture 5 steps darker.
ESC. data ESC.
= 1st Method for downloading data. Data format is binary, where the ESC
characters (ASCII 27 or HEX 1B) have to be replaced first through a double ESC
(ESCESC) to avoid unexpected reactions of the printer.
ESC commands, (requests etc.) can be used during the download of this data.
cab offers the tool: Download.exe (downloadable at http://www.cabgmbh.com ) to
convert existing files.
d BMP;CABLOGO CR ESC. binary data ESC.
Downloads the Graphic: cablogo.BMP to the printer
ESC: data ESCend-of-data
= 2nd Method for downloading data. Data format is binary, starting with ESC: and
followed by ESCend-of-data (ASCII 27 or HEX 1B) followed by ASCII text string
< end-of-data >.
With this method it is allowed that the data stream contains ESC sequences in the
data stream until the ESCendofdata is received.
It is not allowed to send ESC request to the printer during the download time of the
file. The 2nd Method cannot be used in a RS 485 network !
Example:
Example:
