MERKMALE
TECHNIKEN
D
E
P
CARACTERÍSTICAS
TÉCNICAS
CARACTERÍSTICAS
TÉCNICAS
mod. TREND Plus Reverse
C
B
TREND AB C DD
PLUS (mm) (mm) (mm) (mm) (reverse)
600 1.690 920 1.340 335 2240 2300
800 1.690 1.000 1.390 350 2240 2300
1000 1.850 1.190 1.460 480 2350 2600
1500 2.300 1.300 1.520 710 2880 3050
2000 2.300 1.400 1.520 740 2880 3100
3000 2.990 1.725 1.790 900 3570 3790
Kg
A
D
