Back Side
19Y4-009
Rating label
The label shows the serial number, which is needed when making inquiries about the machine. When a
Problem Cannot Be Solved(P. 366)
Rear cover
Open the rear cover when clearing paper jams. Clearing Jams(P. 334)
USB port
Connect a USB cable when connecting the machine and a computer. For connection steps, see "Getting
Started". Manuals Included with the Machine(P. 414)
LAN port
Connect a LAN cable when connecting the machine to a wired LAN router, etc. For connection steps, see
"Getting Started". Manuals Included with the Machine(P. 414)
Power socket
Connect the power cord. For connection steps, see "Getting Started".
Manuals Included with the
Machine(P. 414)
Basic Operations
18
