Scan Area

19Y4-07E

The shaded areas in the table below indicate the scan area of the document. Make sure that text and images in your

documents t within the shaded area. The scan area varies depending on the function used.

Copy

The scan area for copying may differ from the printable area. Printable Area(P. 409)

Scan

Appendix

407
