b
Holder Stopper
Secure rolls on the Roll Holder with this part.
c
Roll Holder Slot
Slide the Roll Holder into this slot.
Carriage
Carriage
a
Printhead Fixer Cover
Holds the Printhead in place. Do not open this part except during Printhead replacement.
b
Printhead
The printhead is equipped with ink nozzles. It serves a key role in printing.
c
Printhead Fixer Lever
Locks the Printhead Fixer Cover. Do not open this part except during Printhead replacement.
Ink Tank Cover (Inside)
Ink Tank Cover (Inside)
Carriage
iPF6400SE
User's Guide
Printer Parts Printer parts
494
