Important
•
This function is not available with Tracing Paper, Translucent Matte Film, or Clear Film.
•
If adjustment is not possible as expected using special media, try another type of paper, or try Manual adjustment.
(See "Manual Adjustment to Straighten Lines and Colors.") ➔P.554
Note
•
Because the results of adjustment vary depending on the type of paper used for adjustment, use the same type of
paper as you will use for printing.
•
If Standard does not improve printing, try adjusting the printhead manually.
(See "Manual Adjustment to Straighten Lines and Colors.")
➔P.554
•
If the printhead position was not adjusted during initial setup or when the printhead was replaced, execute Initial ad-
justmt.
(See "Adjustment When Installing the Printhead.") ➔P.555
Items to Prepare
When Using Rolls An unused roll at least 254.0 mm (10.00 in) wide
When Using Sheets Standard : Two sheets of unused paper, A4/Letter size (or one sheet when using A3 or larger)
Simple: One sheet of unused paper, A4/Letter size
Perform adjustment as follows.
1
Load paper.
•
Loading Rolls on the Roll Holder âž” P.363
•
Loading Rolls in the Printer âž” P.365
•
Loading Sheets in the Feed Slot âž” P.388
Important
•
Always make sure the loaded paper matches the type of paper specified on the printer. Adjustment cannot
be completed correctly unless the loaded paper matches the settings.
2
On the Tab Selection screen of the Control Panel, press â—€ or â–¶ to se-
lect the Settings/Adj. tab ( ).
Note
•
If the Tab Selection screen is not displayed, press the Menu button.
3
Press the OK button.
The Set./Adj. Menu is displayed.
4
Press â–² or â–¼ to select Adjust Printer, and then press the OK button.
5
Press â–² or â–¼ to select Head Posi. Adj., and then press the OK button.
iPF6400SE
Automatic Adjustment to Straighten Lines and Colors
User's Guide
Adjustments for Better Print Quality Adjusting the Printhead
553
To Next Page
