Chapter 1
1-2
1.2 Features
1.2.1 Features
0012-6186
-Rear loading of roll media, making for compact, lightweight device geometry.
-Borderless four-side printing support (roll media) removes laborious cutting work, easing the job of creating
posters to a significant degree.
-High resolutions of 2400 x 1200 dpi maximum, coupled with the exceptionally light-fast, water-proof and
ozone-proof five-color pigment inks of Y, M, C, BK and MBK, deliver high-quality photographic picture
quality.
-High-speed printing under bidirectional print control.
-Ink supply through tubing to a completely independent printhead and large-capacity ink tanks.
-Ready for roll media and cut media.
-Roll media pass in widths between 254 and 914.4 mm and in lengths up to 18 m.
-The cutter unit that mounts on the carriage allows paper to be cut automatically.
-Cut media are fed and ejected and ink tanks replaced all in an easy-to-access front panel operation.
-USB2.0 high-speed interface and 10Base-T/100Base-TX in standard support of a TCP/IP network, plus
optional support of IEEE1394.
1.2.2 Printhead
0013-2741
The printhead that mounts on the carriage is an integrated six-color disposable printhead.
It has 5,120 nozzles for MBK and 2,560 nozzles for each additional color arranged in a zigzag pattern.
If print quality remains unimproved even after a specified cleaning operation, replace the printhead.
Replacement about one year after the date of initial unpacking is also recommended.
F-1-2
