Chapter 8
8-3
8.3 Error Table
8.3.1 Error Code List
The codes correspond to the numbers shown on the DISPLAY in the service mode.
T-8-3
Code Status
03060A00-2E1B End of roll media
03010000-200A Paper width not detected
03010000-200B Incorrect position on platen
03010000-200C Media leading edge not detected
03010000-200D The trailing edge of cut sheet cannot be detected
03010000-200E Too small media
03010000-200F Too large media
03016000-2010 Skewed media
03130031-2F24 Cutter movement timeout
03870001-2015 Cutting failure
03010000-2017 Media right edge not detected
03010000-2018 Media left edge not detected
03862000-2E09 Roll paper running out
03010000-2E19 Media feeding error
03010000-2E1A
03010000-2E1D
03060A00-2E0E Auto Roll Feed Unitnot installed
03010000-2E1C Media cannot be ejected
03180101-2E17 Cassette not loaded
03060200-201E Job requiring cassette was received when "NO" is selected for cassette pick-
up on MIT
03860002-2E0A Manually fed cut sheet was already loaded even though received data
indicated roll media
03060A00-2E00 Roll media was loaded even though the received data indicated roll media.
03861001-2405 Invalid paper position for borderless printing
03861001-2406 Data that does not allow borderless printing was received
03060000-2E14 Width indicated by received data does not match width of paper
03060200-2E03 Cut sheets were not loaded in cassette even though the received data indicated
cut sheets
03061000-2E15
Media type indicated by data does not match
03060000-2E16
Media type and size indicated by data do not match (cassette only)
03060200-2E0B
Manually fed cut sheet was already loaded even though received data
indicated cassette
03010000-2E1F
Too small media for internal printing was loaded
03810104-2500 No ink (BK)
