Chapter 2
2-16
2.3.2.4 Printhead
2.3.2.4.1 Structure of Printhead
0013-6742
The printhead is an integrated assembly of six trains of nozzles. Capable of controlling each nozzle individually,
the printhead implements discharge control for six colors by itself.
a) Nozzle arrangement
The nozzle assembly is formed of 1,280 nozzles arranged at 600-dpi intervals in a zigzag pattern, offering a total
of 2,560 nozzles 1,200-dpi intervals.
F-2-10
0
2
1
3
2559
2557
2558
2556
0
2
1
3
2559
2557
2558
2556
0
2
1
3
2559
2557
2558
2556
0
2
1
3
2559
2557
2558
2556
0
2
1
3
2559
2557
2558
2556
0
2
1
3
2559
2557
2558
2556
5/600inch
1/1200inch
82/600inch
