Chapter 1
1-9
*1
Unidirectional printing may be automatically selected by the print engine according to the type of image to be
printed (such as a graphic image). Unidirectional printing can also be optionally selected from the printer driver.
* 2
Optionally selectable from the printer driver.
* 3
The printer drives an optimal pass count automatically to suit print data.
1.4.2 Interface specifications
0013-4625
a. [USB] (Standard)
(1) Interface Type
USB 2.0, full speed (12 Mbits/sec), high Speed (480 Mbits/sec)
(2) Methods of data transfer
Controlled transfer
Bulk transfer
(3) Signal level
Compliant with the USB standard.
(4) Interface cable
Twisted-pair shielded cable, 5.0 m or shorter
Compliant with the USB standard.
Wire AWG No.28, data line pair (AWG: American Wire Gauge)
AWG No.20 to No.28, distribution line pair
(5) Interface connector
Printer side: USB standard, Series B receptacle
Cable side: USB standard, Series B plug
b. [Network] (Standard)
(1) Interface Type
IEEE802.3-compliant interface
(2) Data transfer method
10Base-T/100Base-TX
(3) Signal level
Input: Threshold.
10Base-T: Max +585mV, min +300mV
100Base-TX: Turn-on +1000mV diff pk-pk, turn-off +200mV diff pk-pk
Output:
10Base-T: +2.2V - + 2.8V
100Base-TX: +0.95V - +1.05V
(4) Interface cable
Category 5 (UTP or FTP) cable, 100 m or shorter
Compliant with the ANSI/EIA/TIA-568A or ANSI/EIA/TIA-568B standard.
(5) Interface connector
Printer side: IEEE802.3 and ANSI X3.263-compliant, ISO/IEC60603-7 standard
Tracing paper(CAD)
translucent mat films(CAD)
Line drawings and
text
Fast (*2) 1 pass Bidirectional 1200 x 1200 dpi
1 pass Bidirectional 1200 x 1200 dpi
Standard 2 passes Bidirectional 1200 x 1200 dpi
Fine (* 2) 4 passes Bidirectional 1200 x 1200 dpi
4 passes Bidirectional 1200 x 1200 dpi
Mediatype Prioritized picture
quality
Print quality Number of
passes
Direction
(*1)
Resolution
