Chapter 6
6-39
40 H1-D-DATA-7-OD OUT Odd head data signal 7(D)
41 H1-E-DATA-8-OD OUT Odd head data signal 8(E)
42 /H1-F-HE-10 OUT Head heat enable signal 10(F)
43 H1-F-DATA-11-EV OUT Even head data signal 11(F)
44 H1-E-DATA-8-EV OUT Even head data signal 8(E)
45 H1-D-DATA-6-EV OUT Even head data signal 6(D)
46 H1-C-DIA2 IN Head DI sensor signal 2(C)
47 H1-C-DATA-5-EV OUT Even head data signal 5(C)
48 H1-B-DIA1 IN Head DI sensor signal 1(B)
49 /H1-A-HE-0 OUT Head heat enable signal 0(A)
50 H1-B-DATA-2-OD OUT Odd head data signal 2(B)
51 H1-B-DATA-3-OD OUT Odd head data signal 3(B)
52 H1-C-DATA-4-OD OUT Odd head data signal 4(C)
53 GND - GND
54 GND - GND
55 GND - GND
56 H1-F-DATA-11-OD OUT Odd head data signal 11(F)
57 H1-E-DATA-9-EV OUT Even head data signal 9(E)
58 GND - GND
59 H1-D-DATA-6-OD OUT Odd head data signal 6(D)
60 /H1-C-HE-5 OUT Head heat enable signal 5(C)
61 /H1-B-HE-3 OUT Head heat enable signal 3(B)
62 H1-A-DIA1 IN Head DI sensor signal 1(A)
63 H1-A-DATA-1-OD OUT Odd head data signal 1(A)
64 GND - GND
65 GND - GND
66 GND - GND
67 GND - GND
68 H1-F-DATA-10-OD OUT Odd head data signal 10(F)
69 H1-F-DIA1 IN Head DI sensor signal 1(F)
70 /H1-D-HE-7 OUT Head heat enable signal 7(D)
71 GND - GND
72 H1_CLK OUT Head clock signal
73 /H1_LT OUT Head latch signal
74 H1-B-DATA-2-EV OUT Even head data signal 2(B)
75 H1-A-DATA-0-OD OUT Odd head data signal 0(A)
76 GND - GND
77 GND - GND
78 GND - GND
J601
Pin
Number
Signal name IN/OUT Function
To Next Page
