Cause
Corrective Action
100 jobs are stored in the Personal Box.
(See "Managing the Job Queue (Deleting or Preempting Other Jobs).")
→
P.765
Delete unneeded jobs stored in personal boxes.
(See "Deleting Saved Jobs.")
→
P.774
iPF8400
Mail box full. Delete unwanted data
User's Guide
Error Message
Messages regarding the hard disk
101
1
1010
1012
Table of Contents
Table of Contents
1
User's Guide
21
Basic Printing Workflow
21
Printing Procedure
22
Printing Options Using Rolls and Sheets
22
Turning the Printer on and off
23
Loading and Printing on Rolls
24
Loading and Printing on Sheets
27
And so on
29
Printing in Windows
29
Printing from Mac os X
30
Canceling Print Jobs
32
Canceling Print Jobs from the Control Panel
32
Canceling Print Jobs from Windows
33
Canceling Print Jobs from Mac os X
33
Pausing Printing
36
User's Guide
37
Choosing Paper for Printing
38
Choosing a Paper for Printing
38
Specifying Paper in the Printer Driver
38
Printing Photos and Office Documents
39
Printing Photos and Images
39
Printing Photos and Images (Windows)
40
Printing Photos and Images (Mac os X)
41
Printing from Photoshop
44
Printing Adobe RGB Images (Windows)
45
Printing Adobe RGB Images (Mac os X)
48
Printing Office Documents
50
Printing Office Documents (Windows)
50
Printing Office Documents (Mac os X)
52
Using Posterartist to Compose Originals
54
Adjusting Images
56
Adjusting the Color in the Printer Driver
56
Fine-Tuning Colors of Photos and Images (Windows)
58
Fine-Tuning Colors of Photos and Images (Mac os X)
60
Giving Priority to Particular Graphic Elements and Colors for Printing
63
Choosing the Document Type and Printing Conditions (Windows)
65
Choosing the Document Type and Printing Conditions (Mac os X)
67
Printing Enlargements or Reductions
70
Resizing Originals to Match the Paper Size
70
Resizing Originals to Match the Paper Size (Windows)
70
Resizing Originals to Match the Paper Size (Mac os X)
72
Resizing Originals to Fit the Roll Width
74
Resizing Originals to Fit the Roll Width (Windows)
75
Resizing Originals to Fit the Roll Width (Mac os X)
77
Resizing Originals by Entering a Scaling Value
80
Resizing Originals by Entering a Scaling Value (Windows)
80
Resizing Originals by Entering a Scaling Value (Mac os X)
82
Printing at Full Size
86
Printing on Oversize Paper
86
Printing at Full Size (Windows)
87
Printing at Full Size (Mac os X)
88
Borderless Printing at Actual Size
91
Borderless Printing at Actual Size (Windows)
92
Borderless Printing at Actual Size (Mac os X)
94
Borderless Printing
94
Enhanced Printing Options
37
Troubleshooting
37
Borderless Printing
98
Borderless Printing on Paper of Equivalent Size
98
Borderless Printing by Resizing Originals to Match the Paper Size (Windows)
99
Borderless Printing by Resizing Originals to Match the Paper Size (Mac os X)
101
Borderless Printing by Resizing Originals to Fit the Roll Width
104
Borderless Printing by Resizing Originals to Fit the Roll Width (Windows)
105
Borderless Printing by Resizing Originals to Fit the Roll Width (Mac os X)
108
Printing Banners or at Other Non-Standard Sizes
111
Printing Vertical or Horizontal Banners (Large-Format Printing)
111
Printing Vertical or Horizontal Banners (Large-Format Printing; Windows)
112
Printing Vertical or Horizontal Banners (Large-Format Printing; Mac os X)
116
Printing on Non-Standard Paper Sizes
119
Printing on Non-Standard Paper Sizes (Windows)
119
Printing on Non-Standard Paper Sizes (Mac os X)
121
Tiling and Multiple Pages Per Sheet
124
Printing Multiple Originals Next to each Other
124
Printing Multiple Originals Next to each Other (Windows)
125
Printing Multiple Originals Next to each Other (Mac os X)
127
Printing Multiple Pages Continuously
128
Printing Multiple Pages Continuously (Windows)
128
Printing Multiple Pages Continuously (Mac os X)
130
Printing Multiple Pages Per Sheet
132
Printing Multiple Pages Per Sheet (Windows)
132
Printing Multiple Pages Per Sheet (Mac os X)
134
Printing Posters in Sections
137
Printing Large Posters (Windows)
138
Centering Originals
141
Printing Originals Centered on Rolls
141
Printing Originals Centered on Rolls (Windows)
141
Printing Originals Centered on Rolls (Mac os X)
143
Printing Originals Centered on Sheets
146
Printing Originals Centered on Sheets (Windows)
146
Printing Originals Centered on Sheets (Mac os X)
148
Conserving Roll Paper
151
Conserving Roll Paper by Rotating Originals 90 Degrees
151
Conserving Roll Paper by Rotating Originals 90 Degrees (Windows)
151
Conserving Roll Paper by Rotating Originals 90 Degrees (Mac os X)
153
Conserving Roll Paper by Printing Originals Without Top and Bottom Margins
155
Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Windows)
156
Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Mac os X)
157
Checking Images before Printing
161
Checking the Layout in a Preview before Printing
161
Other Useful Settings
162
Printing with Watermarks
162
Printing with Watermarks- COPY, FILE COPY, and so on (Windows)
163
Making the Original Orientation Match the Paper Orientation
165
Making the Original Orientation Match the Paper Orientation (Windows)
165
Making the Original Orientation Match the Paper Orientation (Mac os X)
167
Using Favorites
169
Cutting Roll Paper after Printing
170
Cutting Roll Paper after Printing (Windows)
170
Cutting Roll Paper after Printing (Mac os X)
171
