Power Supply Connector
Connect the power cord to this connector.
Top Cover (Inside)
Top Cover (Inside)
a
Top Cover Roller
Prevents paper from rising when ejected.
b
Paper Alignment Line
Align paper with this line when loading it.
c
Carriage
Moves the Printhead. The carriage serves a key role in printing. (See "Carriage.")
→
P.694
d
Carriage Shaft
The Carriage slides along this shaft.
iPF8400
Top Cover (Inside)
User's Guide
Printer Parts Printer parts
693
