Fold Line Type
You can select the fold lines.
The following settings are available for the fold line type.
Setting Details
Solid Line You can print the solid line as the frame style.
Dotted Line You can print the dotted line as the frame style.
Dashed Line You can print the dashed line as the frame style.
•
Only Print Center and Edges
To print fold lines at the center and both edges, select the Only Print Center and Edges checkbox.
Prints using Folded Duplex
Prints using Folded Duplex
This prints 2 pages consecutively. Folding back the paper at the fold lines of the center substitutes for duplex printing.
1
Select two objects from the layout area of Free Layout.
2
Select Folded Duplex from the Edit menu of Free Layout.
Open the Folded Duplex window and arrange the selected objects in the layout area.
3
Open the Finished Size Settings dialog box from the Edit menu.
4
Select Fit Roll Paper Width or Specify Folded Size in Finished Size.
Note
• Rotate Page 90 degrees (Conserve Paper) is also available when Specify Folded Size is selected.
5
Click OK to save the settings.
6
Open the Binding Settings dialog box from the Edit menu.
7
Select Bottom or Top in Binding Edge.
8
Specify the Binding width in Binding.
9
Configure the Fold Line Color and Fold Line Type from Print Fold Lines.
Note
• When the Only Print Center and Edges checkbox is selected, fold lines are only printed at the three locations of
the center and both edges.
10
Click OK to save the settings.
11
Confirm the print setting and begin printing.
iPF8400
Prints using Folded Duplex (Windows)
User's Guide
Windows Software Free Layout
243
