3
Open the Top Cover and lift the Ejection Guide.
4
Holding the Roll Holder so that the side with the white
gear faces the side of the Roll Holder Slot with a white
gear, load the Roll Holder shaft (a) into the grooves (b)
on both ends of the Roll Holder Slot, fully into the slot.
Caution
• Be careful not to drop the roll and hurt yourself when loading it.
• Be careful not to pinch your fingers between the Roll Holder shaft (a) and the guide grooves (b) when loading rolls.
Loading Rolls in the Printer
iPF8400
User's Guide
Handling and Use of Paper Handling rolls
540
To Next Page
