2
Select the
Color Calibration
check box in the
Sound
sheet in the
Preferences
dialog box and then click the
Browse
button and select the audio file.
Note
•
If you want to check the sound in the selected audio file, click the
Test
button.
3
Click the
OK
button.
iPF8400
Getting Audio Notification of Color Calibration Finished (Windows)
User's Guide
Color Management
Color Calibration Management Console (Windows)
873
872
874
