Replacing the Cutter Unit
1
Open the Top Cover.
2
If the Cutter Unit or Carriage Cover is dirty, use a damp cloth that you have wrung out completely to wipe it
clean.
Important
•
Do not touch the Linear Scale (a), Carriage Shaft (b), or
Fixed Blade (c). This may stain your hands and damage
the printer.
3
Push the Cutter Unit Detachment Lever to the left to unlock it.
iPF8400
Replacing the Cutter Unit
User's Guide
Maintenance and Consumables Cutter Unit
931
